FS-1700-12-12-4
.
Details
Details
• Code 61 - OFS Split Flange Adapter
• OFS x FH61
• 1st) 3/4" Male O-Ring Face Seal (1 3/16 - 12 Thread)
• 2nd) 3/4" Code 61 Flange Head (1-1/2" Dia.)
• Black Buna-N 90 Durometer OFS O-Ring
• Carbon Steel
• RoHS Compliant CR6 Free (Clear Zinc Trivalent) Plating
• PCC World-Class Quality Process
• Made to SAE (J518) Flange Specifications
• Uses Split Flange Kit # 61SF-KIT-12
• Working Pressure 5,000 PSI (4:1 Burst)
• Burst Pressure 20,000 PSI
